Processor: Support AMD Sempron™, Athlon, Athlon XP, Duron
FSB 333/266/200MHz processors
Chipset: North Bridge: SiS 741GX, South Bridge: SiS 963L
Memory: 2 x 184 pins DDR Slot, (DDR 333/266, Max 2 GB)
Video: Intergard with Real256E 3D Graphic controller
(64Max share memory)
Slots: 1 x AGP 8X/4X slot(1.5V), 2 x PCI 2.2 slots, 1 x AMR slot
Modem: AMR Modem (Optional)
Highlight Features:
* Support 333/266 MHz
Processors
* Support DDR 333/266
* AGP 8X/4X 1.5V
* Intergard Real 256E 3D Gfx
(Max 64MB)
* 4 USB Ports + (2 VIA header)
* 5.1 Audio Channel
* 10/100 Ethernet LAN
* Hybrid Booster
Audio: Onboard 5.1 Channel, AC97 audio codec
LAN: Onboard 10/100 Ethernet LAN (802.3u), support WOL
I/O (Real): 1 x PS2 Keyboard
1 x PS2 Mouse
1 x Printer Port (LPT 1)
1 x Serial Port (COM Port Bracket)
1 x VGA Port
1 x Audio Port (MIC-IN, LINE-IN, LINE-OUT)
1 x 4 USB 2.0 Ports + 2 ports upgrade via header
1 x Game / MIDI
1 x RJ 45 LAN Port
Connector/
Header: 2 x IDE Connector (ATA 133/100/66 mode)
1 x FDD Connector
1 x ATX Power Connector (20pin)
1 x CPU, System Fan
1 x CD/AUX audio
1 x SIR/CIR
BIOS: AMI 2MB Flash ROM with ACPI, SM BIOS 2.3.1, PnP
Form Factor : Micro ATX
Special
Features: Support WOL, WOR, KB power ON/OFF and interrup
wake up from keyboard/mouse.
Built-in ASRock U-COP™ CPU Overheating Protection
and Hybrid Booster™ Technology
Accessories : Quick Installation Guide, I/O shield
Support CD ( Drivers, Utilities, PC-Cillin 2002 OEM,
ASRock PC DIY Demo)
Floppy/ATA 100 Cables
|
