| I leveransen ingår moderkortet och drivrutin-cd
Processor: Support AMD Sempron™, Athlon, Athlon XP, Duron
FSB 400/333/266MHz processors
Chipset: North Bridge: VIA KT880, South Bridge: VIA 8237
Memory: 4 x DDR Slot (DDR 400/333/266, Max 4 GB)
Dual Channel Technology
Video: N/A
Slots: 1 x ASRock K8 Bridge Port (Orange): Flexible Socket 754
upgrade interface for ASrock 754 Bridge card
1 x AGP1 - AGP8X slot for socket 462
1 x AGP2 - AGP8X slot for socket 754
3 x PCI slots (2.3 compliance)
Highlight Features:
* Support AMD Sempron
Athlon XP, Athlon & Duron
Processors (FSB 400/333/266)
* ASRock K8 Bridge Port:
Flexible socket 754 upgrade
interface for ASRock 754
Bridge card
* Support DDR 400 &
Dual Channel Technology
* AGP 8X/4X 1.5V
* Advanced storage interface
SATA 1.5Gb/s, RAID 0,1 JBOD , SATA HDD Hotplug
* 6 USB Ports + (2 VIA header)
* 5.1 Audio Channel 3D Audio
* 10/100 Ethernet LAN
* Hybrid Booster
Modem: N/A
Audio: CMedia CMI9761 6 Channel AC'97 audio codec
LAN: VIA 6103 10/100 Ethernet LAN (802.3u), support WOL
I/O (Real): 1 x PS2 Keyboard
1 x PS2 Mouse
1 x Printer Port (LPT 1)
1 x Serial Port (COM 1)
1 x Audio Port (MIC-IN, LINE-IN, LINE-OUT)
1 x 6 USB 2.0 Ports + 2 ports upgrade via header
1 x RJ 45 LAN Port
Connector/
Header: 2 x SATA 1.5Gb/s connectors, supports RAID,0,1 JBOD
SATA HDD_Hotplug
2 x IDE Connector (ATA 133/100/66 mode)
1 x FDD Connector
1 x ATX Power Connector (20pin)
1 x ATX 12V Connector (4pin)
1 x CPU, System Fan
1 x CD/AUX audio,(Front panel audio connector)
1 x SIR/CIR
BIOS: AMI 4MB Flash ROM with ACPI, SM BIOS 3.0, PnP
Form Factor : ATX
Special
Features: Support WOL, WOR, KB power ON/OFF and interrup
wake up from keyboard/mouse.
Built-in ASRock U-COP™ CPU Overheating Protection
and Hybrid Booster™ Technology
|
